• SKU: SN00-010265
  • Brand: Sensor Networks Inc.

Sensor Networks 16 Element General Purpose Phased Array Transducer - 2.25 MHz

*you must specify your connector and cable length upon ordering* Phased Array Transducers SNI's phased array transducers are available in many configurations, including linear, matrix,...
REQUEST A QUOTE
  • Competitive Shipping Rates
  • Satisfaction Guaranteed
  • Secure Checkout
  • Description
Description

*you must specify your connector and cable length upon ordering*

Phased Array Transducers
SNI's phased array transducers are available in many configurations, including linear, matrix, dual matrix, curved, annular and annular sectorial. Standard cable length is 8.2-ft (2.5 m) with ZPAC, IPEX, Phasor, Mentor, or Hypertronics connector.

Details for #SN00-010265
Number of Elements: 16
Element Pitch: 0.030" (0.75mm)
Elevation: 0.47" (12mm)
Type: general purpose linear
Case Type: AM
Equivalent: ZPA-PB1D-AM-2.25MHZ-REX-2.5M-ZPAC

Details for #SN00-011419
Number of Elements: 16
Element Pitch: 0.030" (0.75mm)
Elevation: 0.47" (12mm)
Type: general purpose linear
Case Type: A1
Equivalent: 2.25L16-A1

Details for #SN00-010277
Number of Elements: 16
Element Pitch: 0.060" (1.5mm)
Elevation: 0.75" (19mm)
Type: general purpose linear
Case Type: E3
Equivalent: 115-000-450
